Beelink GTR 7, AMD R7 3750H 4.0Ghz, DDR4 16GB RAM, 512GB SSD, Radeon RX Vega 10 Graphics 1400MHz, 5.8G WiFi 6
Features:
- CPU: AMD Ryzen™ 7 3750H, Quad-Core 8 Threads, 2.3Ghz UP TO 4.0Ghz, Cache 6MB
- RAM: 16GB DDR4 RAM (Support 64GB Extension)
- Storage Capacity: 512GB M.2 NVMe PCIe 4X 2280 SSD 1900MB/S
- Expansion: Support M.2 SATA3 2280 /SATA3 HDD 2.5inch
- OS: Windows 10
- WIFI: 802.11 b/g/n/ac/ax 2.4G/5.8G wifi6
- BT: Bluetooth 5.0
- LAN: 1000M
- Decoder Format: H.264, H.265
- Video Format: Support 4K, VP9
- Support 5.1 Surround Sound Output: Yes
- Intelligent Assistant: Support Voice Interaction
- Fingerprint-secured: Set up fingerprint-secured logins
- Dissipation: Built-in excellent cooling fan ensures efficient and rapid heat dissipation
- Interface: 6 x USB 3.0, 2 x HDMI, 2 x LAN, 1 x DP, 1 x Type-C
Package Included:
- 1 x Beelink GT-R 16+512GB Mini PC1 x Power Adapter
- 1 x Wall-Mounted Bracket
- 1 x User Manual
Specification:
| GENERAL | |
|---|---|
| Brand | Beelink |
| Model | GTR 7 |
| Type | Mini Pc |
| HARDWARE | |
|---|---|
| O.S | Windows 10 |
| CPU | AMD Ryzen™ 7 3750H, Quad-Core 8 Threads, 2.3Ghz UP TO 4.0Ghz, Cache 6MB |
| Instruction Set | 64bit |
| Lithography | 12nm |
| Graphics | Radeon™ RX Vega 10 Graphics 1400 MHz |
| RAM | 16GB (SO-DIMM DDR4 2400MHz), Support Up to 64GB |
| Storage | 512GB M.2 NVMe PCIe 4X 2280 SSD 1900MB/S |
| Storage Extension1 | M.2 SATA3 2280 SSD slot |
| Storage Extension2 | Support up to 1TB 2.5 inch SATA hard drive (not include) |
| COMMUNICATION | |
|---|---|
| WIFI | 2.4G/5.8G, 802.11 b/g/n/ac/ax wifi6 |
| Bluetooth | Bluetooth 5.0 |
| LAN | 1000M |
| MEDIA | |
|---|---|
| Decoder Format | H.264, H.265 |
| Video Format | 4K, 4Kx2K, ASF, AVC, AVI, DAT, FLV, ISO, MP4, RM, RMVB, RV, TS, VOB, VP9, WMV |
| Audio Format | AAC, AC3, ACC, APE, DDP, DTS, MKA, MP3, MPEG, OGA, OGG, RM, TrueHD, WAV, WMA |
| Photo Format | BMP, GIF, JPEG, JPG, PNG |
| 5.1 Surround Sound Output | Support |
| OTHER FEATURES | |
|---|---|
| Language | Multi-language |
| HDMI Function | HDCP |
| INTERFACE | |
|---|---|
| Fingerprint Recognition | x 1 |
| DC JACK | x 1 |
| USB 3.0 | x 6 |
| 100/1000M RJ45 | x 2 |
| HDMI (Standard HDMI Connector) | x 2 |
| DP | x 1 |
| MIC (Built-in) | x 2 |
| Audio Jack (HP&MIC) | x 1 |
| Type-C (date/video) | x 1 |
| CLR CMOS Button | x 1 |
| Power Button | x 1 |
| POWER | |
|---|---|
| Power Consumption | 19V/3A |
| Power Type | External Power Adapter |
| Power Supply | Charge Adapter |
| Certification | CE, FCC |
| DIMENSION & WEIGHT | |
|---|---|
| Product weight | 0.666 kg |
| Package weight | 1.363 kg |
| Product size (L x W x H) | 16.80 x 12.00 x 3.90 cm |
| Package size (L x W x H) | 18.00 x 12.90 x 11.00 cm |
| Package Included: | 1 x Beelink GT-R Mini PC 1 x Power Adapter 1 x HDMI Cable 1 x Wall-Mounted Bracket 1 x Installation Guide 1 x User Manual |
